Deutsch Autosport AS Flangeless Connector 61 Way Shell Size 24 Pin Layout 24-61 Style 4 Flangeless Receptacle Red N Keyway Sockets Standard

Deutsch Autosport AS Flangeless Connector 61 Way Shell Size 24 Pin Layout 24-61 Style 4 Flangeless Receptacle Red N Keyway Sockets Standard
Deutsch Autosport AS Flangeless Connector 61 Way Shell Size 24 Pin Layout 24-61 Style 4 Flangeless Receptacle Red N Keyway Sockets Standard
Deutsch Autosport AS Flangeless Connector 61 Way Shell Size 24 Pin Layout 24-61 Style 4 Flangeless Receptacle Red N Keyway Sockets Standard
Deutsch Autosport AS Flangeless Connector 61 Way Shell Size 24 Pin Layout 24-61 Style 4 Flangeless Receptacle Red N Keyway Sockets Standard
Deutsch Autosport AS Flangeless Connector 61 Way Shell Size 24 Pin Layout 24-61 Style 4 Flangeless Receptacle Red N Keyway Sockets Standard
  • Stock: Email For Price & Availability
  • Model: MC03-AS424-61SN-HE
  • Weight: 60.00g
  • SKU: MC03-AS424-61SN-HE
  • UPC: MC03-AS424-6
  • MPN: AS424-61SN-HE
TE Deutsch Autosport TE Deutsch Autosport
Based on 0 reviews. - Write a review
£0.00
Add to Cart
Ask Question
Add to Wish List Compare this Product
Manufacturer
Brand Deutsch
Brand Series Deutsch Autosport
Connector Series AS
Manufacturer TE
Connector Housing Attributes
Keyway Colour N - Red
Pin Pattern 24-61
Pins / Sockets S
Shell Size 24
Total Contacts 61
Wire Sealing Max (mm3) 2.11
Wire Sealing Min (mm3) 1.02
Housing Code 4
Housing Style 4 - Flangeless Recepticle
Keyway Code N
Durability Cycles 500
Dielectric Voltage 1800
Connector Contacts Data - Primary
Primary Contacts Max Amps (A) ** 7.5
Primary Contacts Quantity 61
Primary Contacts Size (awg) 20
Temperature
Temperature Operating Max (Deg C) +175
Temperature Operating Min (Deg C) -55

Tooling & Related Products

Image Product Price Quantity Add
Accessories
Pro Cap
Deutsch Autosport AS Connector Pro Cap Series Shell Size 24 Style 9 Pro Cap For Receptacle All Keyways Standard Deutsch Autosport AS Connector Pro Cap Series Shell Size 24 Style 9 Pro Cap For Receptacle All Keyways Standard
£35.90
Heat Shrink Boots
Hellerman 90Deg Boot
Hellermann Heat Shrink Boot 90deg for AS Shell 20, 22, 24 Hellermann Heat Shrink Boot 90deg for AS Shell 20, 22, 24
£10.98
Hellerman Straight Boot
Hellermann Heat Shrink Boot Straight for AS Shell 20, 22, 24 Hellermann Heat Shrink Boot Straight for AS Shell 20, 22, 24
£8.97
Raychem 90Deg Boot
Raychem Boot 90Deg AS Connector Shell Size 24 Raychem Boot 90Deg AS Connector Shell Size 24
£22.64
Raychem Straight Boot
Raychem Boot Straight AS Connector Shell Size 24 Raychem Boot Straight AS Connector Shell Size 24
£20.32
Mating Connector Options
6 - Free plug
Deutsch Autosport AS Connector 61 Way Shell Size 24 Pin Layout 24-61 Style 6 Free plug Red N Keyway Pins Standard Deutsch Autosport AS Connector 61 Way Shell Size 24 Pin Layout 24-61 Style 6 Free plug Red N Keyway Pins Standard
£183.55
Spare Contacts
Filler Plug
Autosport Connector Filler Plugs for 20g Pins Autosport Connector Filler Plugs for 20g Pins
£0.64
Spare Sockets
Connector Autosport Terminal Socket AS 20awg (Bag of 10) Connector Autosport Terminal Socket AS 20awg (Bag of 10)
£6.51
Tooling
Contact Positioner
Autosport Crimp Tool Positioner for 20g Pins and Sockets Autosport Crimp Tool Positioner for 20g Pins and Sockets
£99.57
Crimp Tool
Autosport Crimp Tool for AS Micro, Mini, ASL, ASR, ASC, ASU Autosport Crimp Tool for AS Micro, Mini, ASL, ASR, ASC, ASU
£673.19
Insert Extract Tool
MoTeC De-pinning Tool Autosport 20g De-pinning Tool (Plastic) MoTeC De-pinning Tool Autosport 20g De-pinning Tool (Plastic)
£4.28
