Deutsch Autosport AS Connector 41 Way Shell Size 20 Pin Layout 20-41 Style 2 PCB Receptacle Flange Mount Red N Keyway Sockets Standard

The Deutsch Autosport AS SERIES connector was developed from the MIL-C-38999 Series 1.5 (Eurofighter connector), the AS Series was the first range of high specification connectors designed specifically for the autosport market. The AS Series offers weight and space saving over standard military designs and is available in a wide variety of options, with medium and high density arrangements, up to 128 ways,4 shell styles, and 5 keyway orientations.

Features

  • 41-Way Autosport AS Series Connector
  • Body Style 2 (2 hole flanged receptacle with PCB contacts) With Sockets
  • Shell Size 20, Contact Arrangement 20-41
  • N Keyway-Red Band
  • 41x 20awg Sockets (Accepts 24,22,20awg Wire) Max 7.5A
  • For Replacement Contacts Use Part Number MC05-3603528-S-PCB
  • Connector Overall Dimensions (Excluding Boot) Length 28x48mm
  • Includes connector body, contacts & Insert-Extract Tool

    See Tooling And Accessories Tab for Mating Connectors, Boots, Spare Contacts And Tooling

    • Manufacturer
    Brand Deutsch
    Brand Series Deutsch Autosport
    Connector Series AS
    Manufacturer TE
    Connector Housing Attributes
    Keyway Colour N - Red
    Pin Pattern 20-41
    Pins / Sockets S
    Shell Size 20
    Total Contacts 41
    Wire Sealing Max (mm3) 2.11
    Wire Sealing Min (mm3) 1.02
    Housing Code 2
    Housing Style 2 - PCB Receptacle Flange Mount
    Keyway Code N
    Durability Cycles 500
    Dielectric Voltage 1800
    Connector Contacts Data - Primary
    Primary Contacts Max Amps (A) ** 7.5
    Primary Contacts Quantity 41
    Primary Contacts Size (awg) 20
    Temperature
    Temperature Operating Max (Deg C) +175
    Temperature Operating Min (Deg C) -55

    Tooling & Related Products

    Image Product Price Quantity Add
    Accessories
    Gasket
    Deutsch Autosport AS Connector Gasket Shell Size 20 All Keyways Standard Deutsch Autosport AS Connector Gasket Shell Size 20 All Keyways Standard
    £15.17
    Nut Plate
    Deutsch Autosport AS Connector Nut Plate Shell Size 20 All Keyways Standard Deutsch Autosport AS Connector Nut Plate Shell Size 20 All Keyways Standard
    £16.21
    Pro Cap
    Deutsch Autosport AS Connector Pro Cap Series Shell Size 20 Style 9 Pro Cap For Receptacle All Keyways Standard Deutsch Autosport AS Connector Pro Cap Series Shell Size 20 Style 9 Pro Cap For Receptacle All Keyways Standard
    £35.90
    Mating Connector Options
    6 - Free plug
    Deutsch Autosport AS Connector 41 Way Shell Size 20 Pin Layout 20-41 Style 6 Free plug Red N Keyway Pins Standard Deutsch Autosport AS Connector 41 Way Shell Size 20 Pin Layout 20-41 Style 6 Free plug Red N Keyway Pins Standard
    £128.64
    Spare Contacts
    Filler Plug
    Autosport Connector Filler Plugs for 20g Pins Autosport Connector Filler Plugs for 20g Pins
    £0.64
    Spare Sockets
    Connector Autosport Terminal Socket AS 20awg (Bag of 10) Connector Autosport Terminal Socket AS 20awg (Bag of 10)
    £6.51
    Tooling
    Contact Positioner
    Autosport Crimp Tool Positioner for 20g Pins and Sockets Autosport Crimp Tool Positioner for 20g Pins and Sockets
    £99.57
    Crimp Tool
    Autosport Crimp Tool for AS Micro, Mini, ASL, ASR, ASC, ASU Autosport Crimp Tool for AS Micro, Mini, ASL, ASR, ASC, ASU
    £673.19
    Insert Extract Tool
    MoTeC De-pinning Tool Autosport 20g De-pinning Tool (Plastic) MoTeC De-pinning Tool Autosport 20g De-pinning Tool (Plastic)
    £4.28
