Deutsch Autosport AS Clinchnut Connector 10 Way Shell Size 12 Pin Layout 12-98 Style 0 Flange Receptacle Red N Keyway Sockets 978M

Deutsch Autosport AS Clinchnut Connector 10 Way Shell Size 12 Pin Layout 12-98 Style 0 Flange Receptacle Red N Keyway Sockets 978M
Deutsch Autosport AS Clinchnut Connector 10 Way Shell Size 12 Pin Layout 12-98 Style 0 Flange Receptacle Red N Keyway Sockets 978M
Deutsch Autosport AS Clinchnut Connector 10 Way Shell Size 12 Pin Layout 12-98 Style 0 Flange Receptacle Red N Keyway Sockets 978M
Deutsch Autosport AS Clinchnut Connector 10 Way Shell Size 12 Pin Layout 12-98 Style 0 Flange Receptacle Red N Keyway Sockets 978M
Deutsch Autosport AS Clinchnut Connector 10 Way Shell Size 12 Pin Layout 12-98 Style 0 Flange Receptacle Red N Keyway Sockets 978M
  • Stock: Email For Price & Availability
  • Model: MC03-AS012-98SN-HE-978M
  • Weight: 30.00g
  • SKU: MC03-AS012-98SN-HE-978M
  • UPC: MC03-AS012-9
  • MPN: AS012-98SN-HE-978M
TE Deutsch Autosport TE Deutsch Autosport
Based on 0 reviews. - Write a review
£0.00
Add to Cart
Ask Question
Add to Wish List Compare this Product
Manufacturer
Brand Deutsch
Brand Series Deutsch Autosport
Connector Series AS
Manufacturer TE
Connector Housing Attributes
Keyway Colour N - Red
Modification Code 978M
Pin Pattern 12-98
Pins / Sockets S
Shell Size 12
Total Contacts 10
Wire Sealing Max (mm3) 2.11
Wire Sealing Min (mm3) 1.02
Housing Code 0
Housing Style 0 - Flange Receptacle
Keyway Code N
Durability Cycles 500
Dielectric Voltage 1800
Connector Contacts Data - Primary
Primary Contacts Max Amps (A) ** 7.5
Primary Contacts Quantity 10
Primary Contacts Size (awg) 20
Temperature
Temperature Operating Max (Deg C) +175
Temperature Operating Min (Deg C) -55

Tooling & Related Products

Image Product Price Quantity Add
Accessories
Gasket
Deutsch Autosport AS Connector Gasket Shell Size 12 All Keyways Standard Deutsch Autosport AS Connector Gasket Shell Size 12 All Keyways Standard
£9.57
Nut Plate
Deutsch Autosport AS Connector Nut Plate Shell Size 12 All Keyways Standard Deutsch Autosport AS Connector Nut Plate Shell Size 12 All Keyways Standard
£16.21
Pro Cap
Deutsch Autosport AS Connector Pro Cap Series Shell Size 12 Style 9 Pro Cap For Receptacle All Keyways Standard Deutsch Autosport AS Connector Pro Cap Series Shell Size 12 Style 9 Pro Cap For Receptacle All Keyways Standard
£35.90
Heat Shrink Boots
Hellerman 90Deg Boot
Hellermann Heat Shrink Boot 90deg for AS Shell 12 Hellermann Heat Shrink Boot 90deg for AS Shell 12
£6.70
Hellerman Straight Boot
Hellermann Heat Shrink Boot Straight for AS Shell 12 Hellermann Heat Shrink Boot Straight for AS Shell 12
£8.88
Raychem 90Deg Boot
Raychem Boot 90Deg AS Connector Shell Size 12 - 14 Raychem Boot 90Deg AS Connector Shell Size 12 - 14
£11.46
Raychem Straight Boot
Raychem Boot Straight AS Connector Shell Size 12 - 14 Raychem Boot Straight AS Connector Shell Size 12 - 14
£9.89
Mating Connector Options
6 - Free plug
Deutsch Autosport AS Connector 10 Way Shell Size 12 Pin Layout 12-98 Style 6 Free plug Red N Keyway Pins Standard Deutsch Autosport AS Connector 10 Way Shell Size 12 Pin Layout 12-98 Style 6 Free plug Red N Keyway Pins Standard
£78.60
Spare Contacts
Filler Plug
Autosport Connector Filler Plugs for 20g Pins Autosport Connector Filler Plugs for 20g Pins
£0.64
Spare Sockets
Connector Autosport Terminal Socket AS 20awg (Bag of 10) Connector Autosport Terminal Socket AS 20awg (Bag of 10)
£6.51
Tooling
Contact Positioner
Autosport Crimp Tool Positioner for 20g Pins and Sockets Autosport Crimp Tool Positioner for 20g Pins and Sockets
£99.57
Crimp Tool
Autosport Crimp Tool for AS Micro, Mini, ASL, ASR, ASC, ASU Autosport Crimp Tool for AS Micro, Mini, ASL, ASR, ASC, ASU
£673.19
Insert Extract Tool
MoTeC De-pinning Tool Autosport 20g De-pinning Tool (Plastic) MoTeC De-pinning Tool Autosport 20g De-pinning Tool (Plastic)
£4.28
