Deutsch Autosport AS Connector 3 Way Shell Size 10 Pin Layout 10-03 Style 1 Inline Receptacle Red N Keyway Pins Standard

Deutsch Autosport AS Connector 3 Way Shell Size 10 Pin Layout 10-03 Style 1 Inline Receptacle Red N Keyway Pins Standard
Deutsch Autosport AS Connector 3 Way Shell Size 10 Pin Layout 10-03 Style 1 Inline Receptacle Red N Keyway Pins Standard
Deutsch Autosport AS Connector 3 Way Shell Size 10 Pin Layout 10-03 Style 1 Inline Receptacle Red N Keyway Pins Standard
Deutsch Autosport AS Connector 3 Way Shell Size 10 Pin Layout 10-03 Style 1 Inline Receptacle Red N Keyway Pins Standard
Deutsch Autosport AS Connector 3 Way Shell Size 10 Pin Layout 10-03 Style 1 Inline Receptacle Red N Keyway Pins Standard
Deutsch Autosport AS Connector 3 Way Shell Size 10 Pin Layout 10-03 Style 1 Inline Receptacle Red N Keyway Pins Standard
Deutsch Autosport AS Connector 3 Way Shell Size 10 Pin Layout 10-03 Style 1 Inline Receptacle Red N Keyway Pins Standard
  • Stock: Email For Price & Availability
  • Model: MC03-AS110-03PN-HE
  • Weight: 20.00g
  • SKU: MC03-AS110-03PN-HE
  • UPC: MC03-AS110-0
  • MPN: AS110-03PN-HE
TE Deutsch Autosport TE Deutsch Autosport
Based on 0 reviews. - Write a review
£52.01
Add to Cart
Ask Question
Add to Wish List Compare this Product
Manufacturer
Brand Deutsch
Brand Series Deutsch Autosport
Connector Series AS
Manufacturer TE
Connector Housing Attributes
Keyway Colour N - Red
Pin Pattern 10-03
Pins / Sockets P
Shell Size 10
Total Contacts 3
Wire Sealing Max (mm3) 2.77
Wire Sealing Min (mm3) 1.65
Housing Code 1
Housing Style 1 - Inline Receptacle
Keyway Code N
Durability Cycles 500
Dielectric Voltage 1800
Connector Contacts Data - Primary
Primary Contacts Max Amps (A) ** 20
Primary Contacts Quantity 3
Primary Contacts Size (awg) 16
Temperature
Temperature Operating Max (Deg C) +175
Temperature Operating Min (Deg C) -55

Tooling & Related Products

Image Product Price Quantity Add
Accessories
Pro Cap
Deutsch Autosport AS Connector Pro Cap Series Shell Size 10 Style 9 Pro Cap For Receptacle All Keyways Standard Deutsch Autosport AS Connector Pro Cap Series Shell Size 10 Style 9 Pro Cap For Receptacle All Keyways Standard
£35.90
Heat Shrink Boots
Hellerman 90Deg Boot
Hellermann Heat Shrink Boot 90deg AS MINI & AS Shell 08, 10 Hellermann Heat Shrink Boot 90deg AS MINI & AS Shell 08, 10
£8.49
Hellerman Straight Boot
Hellermann Heat Shrink Boot Straight for AS MINI & AS 08, 10 Hellermann Heat Shrink Boot Straight for AS MINI & AS 08, 10
£6.93
Raychem 90Deg Boot
Raychem Boot 90Deg AS Connector Shell Size 10 Raychem Boot 90Deg AS Connector Shell Size 10
£9.93
Raychem Straight Boot
Raychem Boot Straight AS Connector Shell Size 10 Raychem Boot Straight AS Connector Shell Size 10
£8.63
Mating Connector Options
6 - Free plug
Deutsch Autosport AS Connector 3 Way Shell Size 10 Pin Layout 10-03 Style 6 Free plug Red N Keyway Sockets Standard Deutsch Autosport AS Connector 3 Way Shell Size 10 Pin Layout 10-03 Style 6 Free plug Red N Keyway Sockets Standard
£0.00
Spare Contacts
Filler Plug
Autosport Connector Filler Plugs for 16awg Contacts Autosport Connector Filler Plugs for 16awg Contacts
£0.80
Spare Pins
Connector Autosport Terminal Pin AS 16 awg (Bag of 10) Connector Autosport Terminal Pin AS 16 awg (Bag of 10)
£7.69
Tooling
Contact Positioner
Autosport Crimp Tool Positioner for 16g Sockets and Pins Autosport Crimp Tool Positioner for 16g Sockets and Pins
£163.59
Crimp Tool
Autosport Crimp Tool for AS 16 Guage Contacts Autosport Crimp Tool for AS 16 Guage Contacts
£0.00
Insert Extract Tool
MoTeC De-pinning Tool Autosport 16g De-pinning Tool (Plastic) MoTeC De-pinning Tool Autosport 16g De-pinning Tool (Plastic)
£6.42
