Deutsch Autosport ASX Micro XtraLITE HE Connector 5 Way Shell Size 02 Pin Layout 02-05 Style 1 Inline Receptacle Red N Keyway Sockets Standard

Following the Micro UltraLite HE connector range, Deutsch UK have introduced a new evolution of Motorsport Micro connectors - the Deutsch Autosport AS Micro XtraLite HE connector. The smallest diameter, lightest AS connector, this new connector offers a solution where space is at its most restrictive.

Features

  • 5-Way Autosport Micro XtraLite (ASX) Series Connector
  • Body Style 1 (Inline receptacle) With Sockets
  • Shell Size 2, Contact Arrangement 02-05
  • N Keyway-Red Band
  • 5x 24awg Sockets (Accepts 30,28,26,24awg Wire) Max 3.0A
  • For Replacement Contacts Use Part Number MC05-8605704-S
  • Connector Overall Dimensions (Excluding Boot) Length 18x10mm
  • Includes connector body, contacts & Insert-Extract Tool

    See Tooling And Accessories Tab for Mating Connectors, Boots, Spare Contacts And Tooling

    • Manufacturer
    Brand Deutsch
    Brand Series Deutsch Autosport Micro XtraLITE HE
    Connector Series ASX
    Manufacturer TE
    Connector Housing Attributes
    Keyway Colour N - Red
    Pin Pattern 02-05
    Pins / Sockets S
    Shell Size 02
    Total Contacts 5
    Wire Sealing Max (mm3) 1.02
    Wire Sealing Min (mm3) 0.56
    Housing Code 1
    Housing Style 1 - Inline Receptacle
    Keyway Code N
    Durability Cycles 500
    Dielectric Voltage 1000
    Connector Contacts Data - Primary
    Primary Contacts Max Amps (A) ** 3
    Primary Contacts Quantity 5
    Primary Contacts Size (awg) 24
    Temperature
    Temperature Operating Max (Deg C) +170
    Temperature Operating Min (Deg C) -55
