MC06-344A0111-18-0 - Type 44 Raychem Cable Single Core18awg Black

MC06-344A0111-18-0 - Type 44 Raychem Cable Single Core18awg Black
MC06-344A0111-18-0 - Type 44 Raychem Cable Single Core18awg Black
  • Stock: Available
  • Model: MC06-344A0111-18-0
  • Weight: 11.67g
  • SKU: MC06-344A0111-18-0
  • UPC: MC06-344A011
  • MPN: 44A0111-18-0
£2.30

Type 44 Raychem Cable Single Core18awg Black

Applications
Raychem Type 44 wire has a dual wall construction that combines the outstanding physical and electrical characteristics of radiation crosslinked polyalkene with the excellent mechanical and chemical properties of radiation crosslinked polyvinylidene fluoride (PVDF).
Raychem Type 44 wire is used extensively throughout industry, applications include commercial wiring avionics, satellites, aircraft, helicopters, ships, trains, offshore platforms and high performance military and motorsport electronics or wherever there is a demand for reliable performance under extreme conditions.
Features
  • Dual wall construction
  • 600 volt rating
  • Small, lightweight and flexible
  • Low smoke and low corrosive gas generation
  • Resistance to most chemicals and electrical arc tracking
  • Colour-Black
  • 18 awg
  • Length-1 Meter
  • <Operating Temperature
  • -65ºC to +150ºC
Connector Housing Attributes
Total Contacts 0
